Lub ntsiab
DMB -9160 A HLS rau ASI IP cultivxer \/ converter yog ib qho kev ua tau zoo, raug nqi them cov teeb meem TV hauv cov chaw ua lag luam. Cov cuab yeej txhawb txhawb qhov siab tshaj plaws ntawm peb Gigamp Chaw Ports (2 cov tswv yim thiab 1 output). Data1 txhawb RTMP \/ http \/ RTSP \/ HLT \/ STP cov tswv yim, thiab cov ntaub ntawv3 txhawb nqa UDP \/ RTTP \/ RTP cov zis (4 MPS \/ 512 SPTS). Txhawb 2 ASI cov tswv yim thiab 4 ASI tsim tawm. Cov cuab yeej txais kev lees paub 1U loj, kev ua kom zoo, kev ua tau zoo, tus nqi qis, muaj kev sib koom ua ke, ruaj khov thiab lwm yam. Ib qho cuab yeej koom ua ke ua tiav cov txheej txheem tiav ntawm cov haujlwm hauv ntej, uas yog qhov haum rau txhua yam tshiab ntawm cov cim TV hauv xov tooj tshaj tawm.
Nta:
Muab 3 qhov chaw nres nkoj gigus tso tawm \/ tso tawm (2 chaw nres nkoj tswv yim, 1 chaw nres nkoj tawm)
Siv 1u chassis, ib qho cuab yeej sib txuas ua ke ib txheej ntawm cov khoom siv tas los, txuag chaw teeb tsa thiab hluav taws xob
Txhawb Nqa Network (Web)
Txhawb Online Ntxiv Rau Online
24 * 7 teev ua haujlwm ruaj khov, xov xwm tshaj tawm
Cov Ntawv Thov
Ntau yam ntawm DTV \/ IPTV \/ CATV tshaj tawm cov tshuab
Faib tus lej rau streaming server hauv IPTV system
Kev tshaj tawm, kev tshuaj xyuas, kev kawm thiab kev qhia.
Kev Lag Luam, Tsev So, Tsev Kawm Ntawv, Tsev Kho Mob, Tsev Noj Mov, Pejxy ETC.
Cim npe nrov: Converter multiplexer, Tuam Tshoj Converter multipexer tuam ntxhab, cov chaw muag khoom, Hoobkas
Cov lus qhia
Video Compression: H.264 \/ AvC
Video Inputs :: 8\/16\/12\/24 HDMI
Los yog sib xyaw tswv yim: HDMI + Tuner DVB-zaus transponders
HDMI + MPEG2 CVBS + Tuners
HDMI + Decrypted Tuners nrog Ci Slots
Tsuas yog HD, SD, Tuners Young Combiner
Cov tswv yim daws teeb meem: 1920x1080 @ 60p, 1920x1080 @ 60i,
1920x1080@50P, 1920x1080@50i,
1280x720@60P, 1280x720@50P
720x576@50i, 720x480@60i
Cov zis daws teeb meem (Max 1080p @ 60 FPS): 1920 × 1080 @vc @ 60p, 1920 × 1080 @ 25p,
1280×720@30P, 1280×720@25P,
720×576@25P, 720×480@30P(Txhawb Nqa 1080P @ 60 FPS Tawm)
Encoding: MPEG -4 Avc \/ H.264, H.265 \/ HEVC (kev xaiv)
BIT-tus nqi: 1MBPS ~ 13MBPS
Tus Nqi Ntsuam Xyuas: CBR, VBR
GOP qauv: IPPPP (pc xoo kev kho, tsis muaj b ncej)
Audio Specifications
Encoding: MPEG -1 txheej 2, LC-AAC, HE-AAC
Kev daws teeb meem: 24- me ntsis
Suab nce: 0-255
BIT-tus nqi: 64kbps, 128kbps, 192kbps, 224kbps, 256kbps, 320kbps, 32kbps
Tus Nqi: 48kHz
IP streaming tawm
RJ45 chaw nres nkoj 100 \/ 1000m GBE chaw nres nkoj
Ib txhij tso zis nrog 512 * SPTS thiab 8 * MPS, UDP \/ RTP
Lim Khall Null Pob Ntawv
Tag nrho bitrate 1-200 Mbps, (yuav tsum muaj ntau dua li encoding bitrate)
MPEG -2} TS dhau UDP \/ RTP, Unicast, thiab multicast streaming
Cov pob ntawv configrable loj: (2-7}) x188bytes
Ntau cov lus qhia tshwj xeeb
Qhov siab tshaj plaws pid remapping 180 cov tswv yim ib channel
Pid remapping los ntawm cia li los yog manually
Raug pccr hloov kho
PSI \/ Si SDI \/ PMT \/ Tot \/ Pat \/ Pat \/ Pat \/ Cat \/ TDT \/ NIT Ntxig
Kev Xaiv Dav Dav
Tswj thiab Saib Xyuas
Interface: 1 * rj -45}, 100 \/ 1000m LAG-T Network interface
Kev ua haujlwm hauv zos: keyboard rau ntawm pem hauv ntej vaj huam sib luag, LCD zaub
Kev tswj chaw taws teeb: Kev Tswj Xyuas Web
Lub cev thiab lub hwj chim
Voltage: 100 rau 120\/200 rau 240V AC ± 10%; 50 \/ 60Hz
Kev Siv: 60W
Kev Ua Haujlwm Kub: {0 ~ 45 degree
Kev ntsuas kub: -20 ~ 80 degree
Tus txheeb ze cov av noo: 10% ~ 90% (tsis-condensing)
Qhov loj me: 482 hli (w) × × 380 (d) hli × 45 hli (h) (19 nti, 1ru)
